Universal ball lock chuck (self centering/floating)
characteristic
- Compatible with both inner and outer diameter clamping
- Excellent rear pull mechanism ensures very stable clamping
- Claw with radial swing function, perfect for gripping workpieces with poor roundness
- Re cutting with minimum clamping amount for workpieces with draft angles
- The clamping of circular motion ensures longer chuck life
- Internal parts can be replaced
- Using special waterproof sealing rings, with excellent waterproof and dustproof capabilities
- Most suitable for rough machining use
Pin spindle chuck (inner diameter PA/outer diameter OPA)
characteristic
- The powerful back pull function ensures that the workpiece firmly fits the positioning block without causing any warping
- Large feeding gap, most suitable for automation
- High rigidity makes the clamping of the inner and outer diameters very stable, with excellent resistance to cutting forces
- Can perform airtight testing on the gripper to better prevent errors during automated processing
(The clamping position of the gripper needs to be within a tolerance of ± 0.03mm in the front sequence for air tightness)
- High speed and good sealing, iron filings cannot enter the inside of the chuck body
- Most suitable for precision machining use
OPA – Jaw rotating chuck
characteristic
- Cross clamping based on high-precision OPA development
- The claw can rotate and has a large opening
- The rotation direction of the claw can be designed according to actual requirements
- Not limited to front loading, it can also be designed as a chuck side loading
- According to actual needs, the rotation direction of the gripper can be designed, with a difference in rotation time, which can achieve high-precision cross clamping that cannot be achieved by a long stroke 3-jaw chuck
Mandrel collet
characteristic
- High torque transmission
- Double cone back pull mechanism
- Spring collet in contact with the octagonal plane of the core shaft
- High precision and stability
- There is a limiter to prevent excessive expansion of the collet
- Can be designed as double tube clamp, eccentric tube clamp, spline tube clamp, composite tube clamp
- Standard products in stock
- Suitable for precision machining inner diameter clamping
Film chuck
characteristic
- Fully sealed construction ensures high service life
- Built in cylinder design, commonly used for spiral machining of scroll parts in air compressors for machining centers
- High repetition accuracy TIR0.002mm
- Easy replacement of claws, positioning blocks, etc
- Suitable for precision machining of lathes, grinders, and machining centers
Pitch chuck
characteristic
- Gear pitch circle chuck developed on the basis of thin film
- The design of the cage can correspond to different sizes of gears, and the cage can be replaced
- Fully sealed construction ensures high service life
- Capable of 3 point clamping, 6 point clamping, pitch circle centering+surface pressing
- Suitable for lathe machining with gear inner diameter
ASA – High speed rotating cylinder system
characteristic
- Maximum speed 12000 rpm
- According to actual needs, 3 or 4 layers of pull rods can be provided
- Customizable length according to spindle requirements
- Can correspond to high-pressure cooling
- Capable of simultaneously achieving central water outlet, central air blowing, and airtight detection functions
AC ultra precision translational chuck
characteristic
- Chuck size 2.5-10 inches
- Claw form: 2 claws, 3 claws, 4 claws
- Repetitive accuracy 0.0015mm
- Fixed gas ring can be added (corresponding to Polaris)
DC ultra precision thin film chuck
characteristic
- Repetitive accuracy within 0.0004mm
- maintenance-free
- Ultra high speed (up to 12000 rpm)
- High lifespan
- Both inner and outer diameter clamping can correspond
- Suitable for use in grinding machines, measurement and precision turning
- Chuck size 3-6 inches (suitable for precision small parts processing)
